Detail E6013
RC-8
For General Purpose and Vertical Down Root Runs
Class of: AWS A5.1 E6013
JIS Z 3211 D4313
DESCRIPTION
RC-8 is a versatile medium cellulose plus content mild steel electrode for all positional welding but particularly advantageous for vertical down welding. This electrode welds with a smooth stable arc on DC but it’ s also well suited for AC welding. Spatter is minimal. Weld seams are smooth, bright and evenly rippled. Initial arc strike and re-strike are instant.
APPLICATIONS
All positional welding but used to particular advantage for vertical down fillet welding of the following and related steel specifications:
Mild and medium carbon-manganese steels up to 15 mm thick with a UTS of 500 N/ mm² max. Typical grades : BS 1449 plate and sheet, BS 4360 grades 43A and 43C, Lloyds A & D ship steel BS 4360 grade 50B Lloyds grades AH and DH, BS 3059 and BS 3601 grade 320-410 API 5L A-B and X42.
INSTRUCTIONS
1.Choose the welding current within the suitable welding current range.
2.Electrodes that have become damp should be re-dried at 110º C for 1 hour.
TYPICAL CHEMICAL COMPOSITION OF WELD METAL ( % )
C Mn Si S P Cr Ni Mo V Fe
0.1
0.5
0.3
0.02
0.02
0.03
0.04
0.01
0.01
Bal.
TYPICAL MECHANICAL PROPERTIES OF WELD METAL
Tensile Strength
Yield Strength
Elongation
545 N/ mm²
55.5 kgf/ mm²
445 N/ mm²
45.4 kgf/ mm²
27%
RECOMMENDED CURRENTS AC or DC
Size( mm) Diameter 2.6 3.2 4.0 5.0
Length 350 350 400 400
Current Range ( Amp.)
60 ~ 110
80 ~ 140
120 ~ 190
160 ~ 230
